Installing Batteries in the Remote

Control

Install two R6 (AA) batteries (supplied) into the remote

control, carefully match with the polarity indicated inside the

battery compartment.

Caution

• Incorrect use of batteries can result in hazards such as

leakage and bursting.

• Do not mix new and old batteries together.

• Do not use different kinds of batteries together.

• Make sure that the plus (+) and minus (–) ends of each

battery match the indications inside the battery

compartment.

• Remove batteries if the equipment will not be used for a

month or more.

• When disposing used batteries, please comply with

governmental regulations or the public instructions for

environmental protection that apply in your country or area.

• Do not recharge, short-circuit, heat, burn or disassemble

batteries.

• Make sure there is no obstacle between the remote control

and the remote control sensor on the unit.

• Use within the operating range and angle as shown.

• The maximum operable range as follows:

• Remote control operation may become unreliable if the

remote control sensor of the unit is being exposed by the

strong sunlight or fluorescent light.

• Remote controls for different devices can interfere with each

other. Be careful when using remote controls for other

equipment located close to the unit.

• Replace the batteries when the operating range of the

remote control reduces.

Switching HDD / DVD / VCR mode

Because this unit is a combination of an HDD, a DVD and a

VCR recorder, you must select which component you want to

operate first.

Press [HDD] on the remote control or the front panel.

(Verify that the HDD indicator is lit in blue.)

Press [DVD] on the remote control or the front panel.

(Verify that the DVD indicator is lit in green.)

Press [VCR] on the remote control or the front panel.

(Verify that the VCR indicator is lit in orange.)

About the Remote Control

Line of sight: approximately 7 m

Either side of centre: approximately 7 m within 30 degrees

21 3

OPEN/CLOSE

DUBBING

VCR REC

ON/STANDBY

VCR HDD DVD HDD DVD

PAL

Within

about 7 m

7 m (30°)7 m

7 m (30°)

HDD

DVD

VCR

OPEN/CLOSE

DUBBING

VCR REC

ON/STANDBY

VCR HDD DVD HDD DVD

PROGRAM

DUBBING

VCR

DVD

VCR

HDD

SELECT HDD/DVD

DVD

REC

DVDHDD

HDD

DVD

VCR

USB

DV IN

PAL

VCR

HDD

SELECT

DVD

REC

Device select indicators

indicator

HDD button

DVD button

button

VCR button

E3TK2BD_EN.book Page 12 Thursday, April 16, 2009 12:00 PM
